Quick Guide to Buying USB-C Cables
January 2025 Ian Chiu
The choice of a USB-C cable is a deciding factor in the connection’s data performance and charging rate. As USB-C cables aren’t exactly a one-size-fits-all affair, most users will find it difficult to find exactly what they need. Things get even more complicated when we have four standards that share USB-C cabling to a varying degree.
Here’s the latest development:
- USB4 can hit 40Gbps over 1m cables certified by USB-IF. Speed however will drop to 20Gbps with 2m passive USB4 cables.
- USB 3.2 can maintain 10Gbps and 20Gbps (depending on the modes) over 1m certified USB-C cables. Go beyond that distance and you will need active extension cables. For sake of simplicity, you want electronically marked USB-C cables that deliver both 100W (20V / 5A) charging rate and 10Gbps connectivity.
- Thunderbolt 3 can transmit at 40Gbps when connected with passive USB-C cables under 0.8m. Active cables will be required to ensure signal integrity for long distances but they also limit data connectivity to Thunderbolt 3 and USB 2.0.
- Thunderbolt 4 can achieve 40Gbps regardless of distance as long as the USB-C cables are Intel-certified for use with said standard.
The upcoming USB Type-C 2.1 cables supporting USB Power Delivery 3.1 with Extended Power Range (EPR) will be able to deliver 240W (48V at 5A). So, looking ahead, power-hungry gaming laptops and even large 4k displays that can be powered exclusively by USB-C will likely make their debut as early as CES 2025.
Without further ado, here’s a list of USB-C cables that we believe are fairly future-proof in the foreseeable future. Everyone who is heavily invested in USB-C devices should give these a look.
Contents
Full-featured USB4 Cable with 240W Power Delivery
When you start to have a dozen or more USB-C cables lying around, trying to figure out which cable is which is a daunting task. After all, not every cable is created equal. This 1m USB Type-C 2.1 cable from Plugable however delivers a nearly no-compromise solution that can serve for years to come.
This is what Plugable calls a “complete” USB4 cable. Not only does it support USB4 speed up to 40Gbps but also carries up to 240W (48V / 5A) of power through the support of USB Power Delivery 3.1. The same cable can handle anything from dual 4k screens to a 5k panel at 60fps and a single 8k display at 30fps. On top of all that, the cable has received USB-IF certification to ensure it maintains the highest level of interoperability as well as backward compatibility with other USB devices.
Perhaps equally important is the new branding for USB-C cables. It brings peace of mind to consumers by helping to identify the capability of a cable. As a full-featured USB4 cable, Plugable’s offering works with Thunderbolt 3/4 out of the box. The company also offers a two-year warranty in case something goes wrong and you need a replacement cable.
- Certified Reliability: USB-IF certified for maximum functionality, the Plugable 1M (3.3ft) USB...
- Maximum Charging Capability: This USB4 Extended Power Range (EPR) cable carries a massive 240W...
- Display and Resolution Support: Enjoy a comprehensive view with this 40Gbps USB4 USB-C cable,...
Splitter USB-C Cable with USB Power Delivery Support
For those of us with single-port USB-C chargers, you most likely find yourself swapping devices to keep them charged. This is where Anker splitter USB-C cable comes in. The base cable measures at 1 meter, with the opposite end splitting into a pair of USB-C cables, each 0.3 meter long. With this cable, you can charge two USB PD devices interrupted. Furthermore, the Anker splitter cable supports up to 140W, provided you have a charger meeting USB Power Delivery 3.1 standard.
Internally, the cable can allocate power output to the two connected devices dynamically based on their power requirements. We briefly tested the 2-in-1 cable with our 15-inch MacBook Pro and 12.9-inch iPad Pro with our Plugable USB PD wattage meter. The notebook was drawing 70W (20V 3.5A) while the tablet was pulling 20W (9V 2.2A) under heavy load. From our tests, the Anker managed to keep both devices charged without trade-offs.
- 2-in-1 Charging Cable: Charge your smartphone and tablet simultaneously with one convenient...
- One Port, 140W Max Charging: Supercharge your 16-inch MacBook Pro (M3 Pro) to 50% in just 20...
- Smart Power Management: Enhance your charging efficiency with this versatile cable, equipped...
Active USB4 Optical Cable with 40Gbps Speeds & USB Power Delivery
USB4 is great for many things, but its range and performance are limited by cable length. Full 40Gbps speeds can be achieved with cables up to 0.8 meters long, while 20Gbps speeds can extend to 2 meters. For longer distances, active optical cables are a viable option. These cables convert electrical USB signals into optical signals, which are then beamed through fiber optics as light.
OWC has such a distance extension solution for USB4 with options for 3m and 4.5m. Both cables support data transfer speeds of up to 40Gbps and USB Power Delivery. The only difference between the two is that the 3m cable delivers 240W of USB PD power whereas 4.5m version can still do 60W.
Since optical fiber does’t carry electricity, OWC’s cables still rely on copper cabling to provide power to connected devices. Both cables are are reinforced with durable nylon braided exterior to improve the wires’ longevity and to reduce EMI/RFI interference. As niche as the use cases are, these cables come in handy in industrial and production environments, where one might need to place a DSLR camera, 8k display, full-featured dock, eGPU box, or SSD RAID storage over longer distances.
- Placement Flexibility: Longer distance connectivity enables optimal placement of USB4 and...
- Uncompromised Speed: Work and play faster with up to 40Gb/s of stable data transfer speed over...
- Versatile Connections: Connect to millions of Thunderbolt 4/3 and USB4/3/2 USB-C equipped...
Braided USB-C Charge Cable with 240W Power Delivery
If you regularly carry around a bunch of USB-C mobile devices that need to be recharged, you should have one or two sufficiently long and durable USB-C cables. This Belkin BoostCharge USB-C cable conforms to USB Power Delivery 3.1 supporting 240W charging but data speeds is limited to that of USB 2.0.
There is actually nothing wrong with Belkin BoostCharge. This has to do with an inherent limitation of the USB 3.2 specs. Optimal performance can only be guaranteed for cables within 1m in length without an active cable extension. Having said that, it doesn’t hurt to carry around a second charge-only cable like Belkin BoostCharge, especially if all your gear charges over USB PD. The cable also features a durable double-braided nylon construction which may prove to be a viable alternative to Apple’s USB-C counterpart. whose easily-deformed design raises durability concerns.
- MADE TO LAST: This USB-C to USB-C cord is designed for lasting use, with a durable anodized...
- EXTRA-LONG CABLE: An ideal choice for personalized style and comfort, this cord is available in...
- OPTIMAL CHARGING SPEEDS: Our BoostCharge charging cable supports fast charging up to 240W for...
USB PD Power Meter
A compact multimeter monitors USB-C charging up to 240W
With the advent of USB Power Delivery 3.1, even power-hungry gaming laptops will soon be powered entirely over USB-C 2.1 cables. The new 140W, 180W, and 240W power levels introduced by the new PD protocol’s 28V, 36V, and 48V voltage support respectively will demand even more powerful, eh, power meters to monitor USB-C charging performance. To that end, Plugable has updated its USB-C Voltage & Amperage Meter to meet the new standards.
This nifty USB dongle is a handy little tool to diagnose charging issues or simply to check the power draw from a USB-C device. The third generation USB multimeter from Plugable now reports back amperage, voltage, and wattage up to 6.5A, 48V, and 240W respectively. Real-time data, as well as directional flow status, is displayed on the Plugable meter’s now improved OLED display with an even brighter than the previous version.
Equally important is the dongle’s ability to allow data passthrough (up to USB 3.1 Gen 2) and USB-C alternate video. Having these makes it possible to diagnose issues for USB-C docks, often equipped with video outputs. The Plugable USB-C Power Meter is by no means a replacement for professional test equipment, not by a long shot. It does give you a start on pinpointing the source of the problem.
- USB C Tester: Monitors USB-C power and charging up to 240W; measures voltage and amperage;...
- Bidirectional: Connects in either orientation for USB Extended Power Range (EPR) voltage from 5...
- Broad USB Support: Functions as a data and power quality meter with USB data pass-through,...
USB-C to USB-A Adapter
Those seeking an alternative solution to replacing their USB-A cables with USB-C counterparts can check out this adapter from Belkin. It’s basically a short USB-C cable tethered to a female USB-A that supports 5Gbps connectivity and delivers a 3A current. This allows more flexibility than what you get with a dongle.
Additionally, it is particularly useful for anything that isn’t likely replaceable with a USB-C version (unless you go with another product). These include wireless transmitters that ship with gaming peripherals and of course, legacy thumb drives. The USB-IF certified dongle will also work flawlessly with the latest Android smartphones and tablets if you need quick access to your existing USB peripherals.
- CHARGE AND SYNC YOUR DEVICES: The Belkin USB C to USB Adapter lets you charge your USB-C device...
- POWER & CHARGE OTHER DEVICES: This USB-C to USB adapter supports up to 3A of power output and...
- REVERSIBLE USB C CONNECTOR: Never worry about which way to plug in again. USB C is a...
